GFA TS 959 - Electrical Installation; Overview Connection Cable XES

11
Overview connection cable DES/NES
DES
NES
: DES/NES
: X12
: MOT : X13 : X12
Ⓐ
DES
↔ Ⓑ
X12
Ⓒ
MOT
↔ Ⓓ
X13
Pin
Core
Pin
Description
Pin
Core
Kl.
Description
①
5/ws
①
Safety circuit +24 V
①
3
W
Phase W
②
6/br
②
Channel B
(RS485)
②
2
V
Phase V
③
7/gn
③
Ground
③
1
U
Phase U
④
8/ge
④
Channel A (RS485)
④
4
N
Neutral conductor (N)
⑤
9/gr
⑤
Safety circuit
⑤
PE
PE
⑥
10/rs
⑥
Supply voltage 8 V DC
Ⓐ
NES
↔ Ⓔ
X12
Pin
Core
Kl.
Description
①
5/ws
11
Limit
switch common +24 V, wire link to: 7, 9, 5, 14v
②
6/br
12
S5 Auxiliary limit switch
③
7/gn
6
S3 OPEN limit switch
④
8/ge
15
S6 Auxiliary limit switch
⑤
9/gr
8
S4 CLOSE limit switch
⑥
10/rs
4
Safety circuit
