Menu items:
P 0.1 - Operating mode
With this menu item, you select the operating mode for moving the door during OPEN operation and CLOSE
operation.
WARNI
NG
Danger due
to unattended door movement!
The safety devices are deactivated in operating mode hold-to-run. People or objects in the movement path
are not detected.

Operate the door only with a clear view of the door.
0. 1
Operating mode
►
.1
No safety device on door: hold-to-run OPEN/CLOSE
.2
No safety device on door: self-hold OPEN and hold-to-run CLOSE
.5
Hold
-
to
-
run fully CLOSE function
No safety device on door: self-hold OPEN and hold-to-run CLOSE In the travel direction CLOSE, the
CLOSE button must be held down until the pre-limit switch (S5 on NES) is passed. Otherwise, the
door moves back to final limit position OPEN.
P 0.2 - Output rotating direction
Use this menu item to change the output rotation direction of the door drive unit.
0.2
Output rotating direction
Select the options with the
OPEN
or
CLOSE
button
.0
Maintaining the output rotation direction.
Exit the menu item by pressing the selector switch.
.1
Changing the output rotating direction.
Save and exit the menu item by pressing the
STOP
button for
3 seconds
.
P 1.1 / 1.2 - Coarse correction of final limit position
Use these menu items to modify the final limit positions of the door that have been already set.
1.1
Coarse correction of final limit position OPEN (DES)
1.2
Coarse correction of final limit position CLOSE (DES)

Move to the desired door position using the
OPEN
or
CLOSE button
.

Save the door position by pressing the
STOP
button once.
WARNI
NG
Danger due to unattended door movement!
The safety devices are deactivated while adjusting.

Block the door for
pedestrians and vehicles
.
