GFA TS 959 - Product Overview; Technical Data

7
Overview display TS 959
2.1 2.2
20.1
1.8 1.9
20.2 20.3
F1 = 1,6A t
V1
M
O T
DES/
NES
S11
S12
S13
X20
X3
X2
X4
X5
F1
S
X1
959
1.5
1.6 1.7
DES/
NES
DES or NES limit switch socket
MOT
Motor socket
V1
Display
S
Selector switch
X1
Mains supply
S11
OPEN push
-
button
X2
Door safety switch
S12
STOP push
-
button
X3
Emergency STOP control device
S13
CLOSE push
-
button
X5
Control device, external three push
-
button
F1
Micro
-
fuse 1.6 A time
-
lag
X20
Potential
-
free relay contact
