P 1.3 – 1.4 - Fine correction of final limit positions
Use this menu item to modify the final limit positions of the door that have been already set. No door
movement takes place during fine correction. Proceed step by step.
1.3
Fine correction of final limit position OPEN (DES)
1.4
Fine correction of final limit position CLOSE (DES)
9
Correction in direction of final limit position CLOSE
_.9
Correction in direction of final limit position OPEN
P 1.7 - Switching position of relay X20
You only have to teach-in this switching position if you want to use the options .1 / .2 or 1. 1 of menu item 2.7.
With this menu item you can set the door position in which relay X20 switches. To use this function, you must
set menu item P 2.7 and connect a device to X20. This menu item is only available in combination with an
ELEKTROMATEN with a digital limit switch.
WARNI
NG
Danger due to unattended door movement!
The safety devices are deactivated while adjusting.

Block the door for pedestrians and vehicles
.
1.7
Setting the switching position of relay X20

Move to the desired door position using the OPEN or CLOSE
button.

Save the door position by pressing the STOP button once.
P 2.7 - Relay functions of X20
Use menu item 2.7 to control the function of X20. X20 is a potential-free relay contact.
2.7
Relay functions of X20

.0
Deactivated
.1
Impulse of 1 second during OPEN operation at switching position.
Switching position requires teach-in with 1.7
.2
Permanent contact from switching position.
Switching position requires teach-in with 1.7
.5
Flashing light: permanent contact during door movement.
In final limit position OPEN: lights up for 3 seconds.
In
final limit position CLOSE: lights up for 3 seconds.
.6
Flashing light: permanent contact during door movement.
In final limit position OPEN: lights up for 3 seconds.
In final limit position CLOSE: off.
1.3
Clearance dock leveller
Active only in final
limit position OPEN
