pag. 16
Release 00 - 02/2008
Engine WBE 0701-WBE 0704
Service manual
5.1. Emptying and removing the tank
1 - Remove the ring (1) of the petrol pipe (2) from
the tank side and drain all the fuel from the tank
and the pipe into a suitable container.
2 - Unscrew the two screws (3) at the side and the
nut at the rear (4) and remove the tank (5).
3 - When tting, perform the above operations in
reverse.
WARNING:Beforerellingthetankwithnew
fuel, check that the petrol pipe is intact.
5.2. Cleaning the tank
1 - Remove the tank [ 5.1].
2 - Remove the clamp (1) from the side of the tank
and disconnect the petrol pipe (2).
3 - Slide out the lter tube (6) and blow compressed
air through it so as to remove any deposits inside.
4 - Keeping the hole (7) in the spigot closed, pour
about 100 cc of clean petrol into the tank and
shake it vigorously to clean the inside.
5. TANK AND SUPPLY
5
3
4
3
6
7
6
2
