Release 00 - 02/2008
Engine WBE 0701-WBE 0704
pag. 17
Service manual
5. TANK AND SUPPLY
5 - Empty the tank and dispose of the petrol used
for cleaning in accordance with the laws in force.
6 - Ret the tank [ 5.1] tightening the screws (3)
and the nut (4) to the torques indicated.
WARNING:Beforerellingthetankwithnew
fuel, check that the petrol pipe is intact.
5.3. Checking and cleaning the breather pipe
1 - Remove the cap (8) and pull out the gasket (9)
and the sponge (10).
2 - Check that:
- the gasket (9) is intact and without cracks or
ssures;
- the air passages (11) inside the cap are not clog-
ged;
- the sponge (10) is not crushed or broken.
NOTE: Always replace the entire cap if the
gasket or sponge is damaged.
Tightening torques
3 Tank xing screws 8-10 Nm
4 Tank xing nut 8-10 Nm
8
8
9
10
11
