Giga-tronics 80350A - 80352 A HI PWR PEAK POWER SENSOR, 25 W, Rev. C

80352A HI PWR PEAK POWER SENSOR, 25W, Rev. C
Item Part Number Qty Cage Mfr’s Part Number Description
1 21474 REF 58900 21474 MDL 80352A SENSOR,N,18GHZ,25W
2 21497 REF 58900 21497 SCHEMATIC,80350 SENSOR
3 16718 REF 05AJ8 COMPOUND 340 THERMAL GREASE
4 HT00-10809 4 58900 HT00-10809 8 NYLON CABLE TIE
5 17274-001 3 58900 17274-001 SPRING, DISC, BELLEVILLE, MOD.
6 PS00-00003 1 53387 2110-11X15 STATIC SHIELDING BAG
7 21425 1 64671 18N25W-30DB ATTEN,25W,30DB
8 21469 1 58900 21469 SLEEVE
9 21470 1 58900 21470 PLATE,HOUSING END
10 21486 1 58900 21486 LABEL,80352A,18GHZ,25W
11 HIWP-00250 4 06383 T25N-M .25 OD SPIRAL WRAP
12 AT00-00007 1 06915 HRT-1 SPIRAL WRAPPING TOOL
13 21568 1 58900 21568 MANUAL,80350A
14 21571 REF 58900 21571 PSD,MDL 80352A,SENSOR
15 21577 REF 58900 21577 SCD,MDL 80352A,SENSOR
16 60338 REF 58900 60338 8035x SERIES TEST PROC
101 HWSS-20200 2 58900 HWSS-20200 #2 X 1/8 SPLIT LOCK
102 HBFP-25604 2 58900 HBFP-25604 2-56 X 1/4 FLAT
103 HBPP-25608 2 58900 HBPP-25608 2-56 X 1/2 PAN
A1 21350 1 58900 21350 PCB ASSY,ANALOG
A2 21353 1 58900 21353 PCB ASSY,DIGITAL
A3 15183 1 58900 15183 TYPE N 18.5GHZ DET.HSG.ASSY
A4 21471 1 58900 21471 SENSOR HOUSING ASSY
A5 21563 1 58900 21563 DET ELEMENT,UNTESTED,80350A
W1 21460-001 1 74970 21460-XXX 6 FT WHITE SMB-BNC CABLE
W2 21460-002 1 74970 21460-002 6 FT RED SMB-BNC CABLE
W3 21460-003 1 74970 21460-XXX 6 FT BLACK SMB-BNC CABLE
Parts Lists
Manual 21568, Rev. F, March 2008 6-3
