Parts Lists
Manual 21568, Rev. F, March 2008 6-9
R18 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R19 RK45-41000 1 59124 RN73K2A1004F 1M OHM 1% FILM SMT
R21 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R27 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R28 RK45-00499 1 ——- RK73H2AT49R9F 49.9 OHM 1% FILM SMT
R32 RK45-00000 1 ——- RM73Z2AT 0 OHM JUMPER SMT
R33 RASD-31000 1 5Y491 84PR100K 100K OHM POT 15T SURF MT
R37 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R38 RK45-01000 1 ——- RK73H2AT1000F 100 OHM 1% FILM SMT
R39 RK45-01000 1 ——- RK73H2AT1000F 100 OHM 1% FILM SMT
R40 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R42 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R46 RK45-04990 1 ——- RK73H2AT4990F 499 OHM 1% FILM SMT
R47 RK45-04990 1 ——- RK73H2AT4990F 499 OHM 1% FILM SMT
R53 RK45-00000 1 ——- RM73Z2AT 0 OHM JUMPER SMT
R54 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R55 RK45-04530 1 ——- RK73H2AT4530F 453 OHM 1% FILM SMT
R56 RK45-04530 1 ——- RK73H2AT4530F 453 OHM 1% FILM SMT
R59 RK45-01000 1 ——- RK73H2AT1000F 100 OHM 1% FILM SMT
R64 RK45-01000 1 ——- RK73H2AT1000F 100 OHM 1% FILM SMT
R77 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R78 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R79 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R80 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R81 RK45-21000 1 ——- RK73H2AT1002F 10.0K OHM 1% FILM SMT
R100 RK45-12000 1 ——- RK73H2AT2001F 2.00K OHM 1% FILM SMT
R101 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R103 RK45-21000 1 ——- RK73H2AT1002F 10.0K OHM 1% FILM SMT
R104 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R105 RK45-02430 1 ——- RK73H2AT2430F 243 OHM 1% FILM SMT
R106 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R107 RK45-01000 1 ——- RK73H2AT1000F 100 OHM 1% FILM SMT
R108 RK45-00499 1 ——- RK73H2AT49R9F 49.9 OHM 1% FILM SMT
R109 RK45-00499 1 ——- RK73H2AT49R9F 49.9 OHM 1% FILM SMT
R110 RK45-00499 1 ——- RK73H2AT49R9F 49.9 OHM 1% FILM SMT
R111 RK45-00499 1 ——- RK73H2AT49R9F 49.9 OHM 1% FILM SMT
R118 RK45-04990 1 ——- RK73H2AT4990F 499 OHM 1% FILM SMT
R119 RK45-12000 1 ——- RK73H2AT2001F 2.00K OHM 1% FILM SMT
R120 RK45-22000 1 ——- RK73H2AT2002F 20.0K OHM 1% FILM SMT
R121 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R125 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R126 RK45-21000 1 ——- RK73H2AT1002F 10.0K OHM 1% FILM SMT
R127 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R128 RK45-21000 1 ——- RK73H2AT1002F 10.0K OHM 1% FILM SMT
R134 RK45-14990 1 ——- RK73H2AT4991F 4.99K OHM 1% FILM SMT
TP3 ETI0-10018 1 58900 ETI0-10018 BLACK TEST POINT
TP11 ETI0-10018 1 58900 ETI0-10018 BLACK TEST POINT
TP12 ETI0-10018 1 58900 ETI0-10018 BLACK TEST POINT
U1 LD0S-00500 1 58900 LD0S-00500 50 NS FIXED DELAY LINE
U2 LD0S-00500 1 58900 LD0S-00500 50 NS FIXED DELAY LINE
U3 UFD0-00829 1 24355 AD829JR AD829JR VIDEO OP AMP
U4 UFD0-00829 1 24355 AD829JR AD829JR VIDEO OP AMP
U5 UFD0-00829 1 24355 AD829JR AD829JR VIDEO OP AMP
U6 UFD0-00829 1 24355 AD829JR AD829JR VIDEO OP AMP
U7 UFD0-00648 1 24355 AD648JR AD648JR BIFET OP AMP
U8 UFD0-00648 1 24355 AD648JR AD648JR BIFET OP AMP
U9 UID0-08043 1 58900 UID0-08043 DAC8043FS 12 BIT D/A
U10 ULD0-00611 1 17856 DG611DY DG611DY QUAD SPST SWITCH
U11 ULD0-00611 1 17856 DG611DY DG611DY QUAD SPST SWITCH
21350 ANALOG PCB ASSY (A1), Rev. P (Continued)
Item Part Number Qty Cage Mfr’s Part Number Description
