Giga-tronics 80350A - ANALOG PCB ASSY (A1), Rev. P

Series 8035XA Peak Power Sensors
6-8 Manual 21568, Rev. F, March 2008
21350 ANALOG PCB ASSY (A1), Rev. P
Item Part Number Qty Cage Mfr’s Part Number Description
1 21349 1 58900 21349 PCB,ANALOG
2 60340 REF 58900 60340 80350 ANALOG PCA TEST PROC
C1 CF63-R3100 1 68919 MKS2-0.01UF-5%-63 .01UF 63V POLYESTER
C2 CF63-R4100 1 68919 MKS2-0.1UF-10%-63 .1UF 63V POLYESTER
C3 CK50-00047 1 72982 GRH708C0G4R7D200AL 4.7PF COG CHIP CERAMIC
C5 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C6 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C7 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C8 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C9 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C10 CK50-00047 1 72982 GRH708C0G4R7D200AL 4.7PF COG CHIP CERAMIC
C11 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C12 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C13 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C14 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C15 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C16 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C21 CK50-02101 1 04222 08055A102JTN 1000 PF NPO CHIP CERAMIC
C22 CK50-00047 1 72982 GRH708C0G4R7D200AL 4.7PF COG CHIP CERAMIC
C23 CK50-00047 1 72982 GRH708C0G4R7D200AL 4.7PF COG CHIP CERAMIC
C24 CK50-00047 1 72982 GRH708C0G4R7D200AL 4.7PF COG CHIP CERAMIC
C31 CK60-04100 1 04222 12105C104KTN .1 UF X7R CHIP CERAMIC
C51 CT25-S6101 1 04222 TAJD106M025R 10 UF 25V TANTALUM SMT
C52 CT25-S6101 1 04222 TAJD106M025R 10 UF 25V TANTALUM SMT
C53 CT25-S6101 1 04222 TAJD106M025R 10 UF 25V TANTALUM SMT
C54 CT25-S6101 1 04222 TAJD106M025R 10 UF 25V TANTALUM SMT
C58 CK50-00470 1 04222 08055A470JATMA 47PF COG CHIP CERAMIC
C59 CK50-00470 1 04222 08055A470JATMA 47PF COG CHIP CERAMIC
C63 CK50-00470 1 04222 08055A470JATMA 47PF COG CHIP CERAMIC
C66 CK50-00047 1 72982 GRH708C0G4R7D200AL 4.7PF COG CHIP CERAMIC
C67 CK50-00047 1 72982 GRH708C0G4R7D200AL 4.7PF COG CHIP CERAMIC
C68 CK50-00047 1 72982 GRH708C0G4R7D200AL 4.7PF COG CHIP CERAMIC
C70 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C71 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C72 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C73 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C74 CF63-R4100 1 68919 MKS2-0.1UF-10%-63 .1UF 63V POLYESTER
C75 CK50-01100 1 58900 CK50-01100 100 PF CERAMIC NPO
C76 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C80 CK50-03100 1 31433 C0805C103K5RAC .01 UF X7R CHIP
C81 CK50-00100 1 54583 CC0805HNPO15150J 10 PF NPO CHIP
CR1 DZCA-05231 1 04713 MMBZ5231B MMBZ5231B 5.1V ZENER SMT
CR2 DSC0-00914 1 04713 MMBD914L MMBD914L SW. DIODE SMT
CR3 DSC0-00914 1 04713 MMBD914L MMBD914L SW. DIODE SMT
CR8 DZCA-05240 1 04713 MMBZ5240B MMBZ5240B 10V ZENER SMT
CR9 DZCA-05240 1 04713 MMBZ5240B MMBZ5240B 10V ZENER SMT
J1 JIA1-07118 1 58900 JIA1-07118 7 PIN STRIPLINE PLUG
J2 JIA1-13125 1 55322 BBL-113-T-E 13 PIN PLUG STRIP
R1 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R2 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R3 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R7 RK45-12210 1 ——- RK73H2AT2211F 2.21K OHM 1% FILM SMT
R8 RK45-41000 1 59124 RN73K2A1004F 1M OHM 1% FILM SMT
R9 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R10 RK45-01000 1 ——- RK73H2AT1000F 100 OHM 1% FILM SMT
R11 RK45-21000 1 ——- RK73H2AT1002F 10.0K OHM 1% FILM SMT
R12 RK45-21000 1 ——- RK73H2AT1002F 10.0K OHM 1% FILM SMT
R14 RK45-13010 1 ——- RK73H2AT3011F 3.01K OHM 1% FILM SMT
