Giga-tronics 80350A - 80355 A HI PWR PEAK POWER SENSOR, 50 W, Rev. C; 32133 SENSOR-S-CLOCK-BUFFER PCA, Rev. a

80355A HI PWR PEAK POWER SENSOR, 50W, Rev. C
Item Part Number Qty Cage Mfr’s Part Number Description
1 21477 REF 58900 21477 MDL 80355A SENSOR,N,18GHZ,50W
2 21497 REF 58900 21497 SCHEMATIC,80350 SENSOR
3 16718 REF 05AJ8 COMPOUND 340 THERMAL GREASE
4 HT00-10809 4 58900 HT00-10809 8 NYLON CABLE TIE
5 17274-001 3 58900 17274-001 SPRING, DISC, BELLEVILLE, MOD.
6 PS00-00003 1 53387 2110-11X15 STATIC SHIELDING BAG
7 21424 1 64671 18N50W-30DB ATTEN,50W,30DB
8 21469 1 58900 21469 SLEEVE
9 21470 1 58900 21470 PLATE,HOUSING END
10 21489 1 58900 21489 LABEL,80355A,18GHZ,50W
11 HIWP-00250 4 06383 T25N-M .25 OD SPIRAL WRAP
12 AT00-00007 1 06915 HRT-1 SPIRAL WRAPPING TOOL
13 21568 1 58900 21568 MANUAL,80350A
14 21574 1 58900 21574 PSD,MDL 80355A,SENSOR
15 21580 1 58900 21580 SCD,MDL 80355A,SENSOR
16 60338 1 58900 60338 8035x SERIES TEST PROC
101 HWSS-20200 2 58900 HWSS-20200 #2 X 1/8 SPLIT LOCK
102 HBFP-25604 2 58900 HBFP-25604 2-56 X 1/4 FLAT
103 HBPP-25608 2 58900 HBPP-25608 2-56 X 1/2 PAN
A1 21350 1 58900 21350 PCB ASSY,ANALOG
A2 21353 1 58900 21353 PCB ASSY,DIGITAL
A3 15183 1 58900 15183 TYPE N 18.5GHZ DET.HSG.ASSY
A4 21471 1 58900 21471 SENSOR HOUSING ASSY
A5 21563 1 58900 21563 DET ELEMENT,UNTESTED,80350A
W1 21460-001 1 74970 21460-XXX 6 FT WHITE SMB-BNC CABLE
W2 21460-002 1 74970 21460-002 6 FT RED SMB-BNC CABLE
W3 21460-003 1 74970 21460-XXX 6 FT BLACK SMB-BNC CABLE
32133 SENSOR-S-CLOCK-BUFFER PCA, Rev. A
Item Part Number Qty Cage Mfr’s Part Number Description
1 32132 1 59800 32132 SENSOR-S-CLK-BUFFER PCB
2 32134 REF 59800 32134 SENSOR-S-CLK-BUFFER SCH
R1 RK40-11000 1 91637 CRCW06031001FRT1 1.0K OHM 1% FILM SMT
R2 RK40-31000 1 04222 CRCW06031003FRT1 100K OHM 1% FILM SMT
U1 UTD3-00322 1 58900 UTD3-00322 MC74HC1G32DFT2 SGL OR SM
Series 8035XA Peak Power Sensors
6-6 Manual 21568, Rev. F, March 2008
