Parts Lists
Manual 21568, Rev. F, March 2008 6-11
R5 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R8 RK45-41000 1 59124 RN73K2A1004F 1M OHM 1% FILM SMT
R9 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R10 RK45-32000 1 ——- RK73H2AT2003F 200K OHM 1% FILM SMT
R12 RK45-21000 1 ——- RK73H2AT1002F 10.0K OHM 1% FILM SMT
R15 RK45-01000 1 ——- RK73H2AT1000F 100 OHM 1% FILM SMT
R16 RK45-01000 1 ——- RK73H2AT1000F 100 OHM 1% FILM SMT
R17 RK45-00499 1 ——- RK73H2AT49R9F 49.9 OHM 1% FILM SMT
R30 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R32 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R33 RK45-31000 1 ——- RK73H2AT1003F 100K OHM 1% FILM SMT
R34 RK45-14990 1 ——- RK73H2AT4991F 4.99K OHM 1% FILM SMT
R35 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R37 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R40 RK45-00100 1 ——- RK73H2AT10R0F 10.0 OHM 1% FILM SMT
R41 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R42 RK45-41000 1 59124 RN73K2A1004F 1M OHM 1% FILM SMT
R43 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R44 RK45-11000 1 65940 MCR10EZFHFX1001 1.00K OHM 1% FILM SMT
R46 RK45-21000 1 ——- RK73H2AT1002F 10.0K OHM 1% FILM SMT
RT1 RTC2-21000 1 56866 QTMC-14 10 K OHM THERMISTOR
U1 UTD0-01636 1 04713 MC74ACT163D 74ACT163D BIN COUNTER SMT
U2 UTD0-01642 1 04713 MC74HC164D MC74HC164D SHIFT REGISTER
U3 21526 1 58900 21526 DELAY LINE ASSY
U4 UTD0-00102 1 58900 UTD0-00102 74HC10D 3 INPUT NAND SMT
U5 UTD0-01636 1 04713 MC74ACT163D 74ACT163D BIN COUNTER SMT
U6 UTD0-01636 1 04713 MC74ACT163D 74ACT163D BIN COUNTER SMT
U7 UTD0-00749 1 04713 MC74AC74D 74VHC74M DUAL D FF SMT
U8 UTD0-00749 1 04713 MC74AC74D 74VHC74M DUAL D FF SMT
U9 UTD0-00024 1 04713 MC74F02D 74F02D QUAD 2IN NOR
U10 UTD0-45382 1 66958 M74HC4538M1 MM74HC4538M DUAL MULTI
U11 UMD1-02404 1 60395 X24C04S14 ( SM ) X24C04S14 512 x 8 EEPROM
U12 UTD0-45382 1 66958 M74HC4538M1 MM74HC4538M DUAL MULTI
U13 UIN1-01020 1 0B0A9 DS1020S-50 DS1020S-25 PROG DELAY
U14 UTD0-01642 1 04713 MC74HC164D MC74HC164D SHIFT REGISTER
U15 UTD0-01636 1 04713 MC74ACT163D 74ACT163D BIN COUNTER SMT
U16 UTD0-01636 1 04713 MC74ACT163D 74ACT163D BIN COUNTER SMT
U17 UTD0-01642 1 04713 MC74HC164D MC74HC164D SHIFT REGISTER
U18 ULD0-01016 1 64155 LT1016CS8 LT1016CS8 COMPARATOR
21353 DIGITAL PCB ASSY (A2), Rev. Z
Item Part Number Qty Cage Mfr’s Part Number Description
