Hardware Installation - 12 -
Internal
Connectors
 1 x 24-pin ATX main power connector
 2 x 8-pin ATX 12V power connector
 2 x Mini-SAS HD connectors
 10 x SATA3 6Gb/s connectors
 1 x PMBus header
 2 x CPU fan headers
 5 x System fan headers
 1 x Front panel header
 1 x HDD Back plane borad header
 1 x USB 3.0 header
 1 x TPM module connector
 1 x SATA SPGIO header
 1 x sSATA SPGIO header
 1 x IPMB connector
 1 x Software RAID key connector
 1 x LSI RAID key connector
Rear Panel I/O  2 x USB 3.0 ports
 3 x RJ-45 ports (1 x 10/100/1000 dedicated management LAN port)
 1 x COM port
 1 x VGA port
 1 x ID Button/LED
I/O Controller  ASPEED
®
AST2400 BMC chip
Hardware
Monitor
 System voltage detection
 CPU/System temperature detection
 CPU/System fan speed detection
 CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
BIOS  1x128Mbitash
 AMI BIOS
Form Factor  EATX Form Factor; 13 inch x 12 inch
*GIGABYTEreservestherighttomakeanychangestotheproductspecicationsandproduct-relatedinformationwithout
prior notice.
