- 83 -
BIOS Setup
2-3-7
PCH Conguration
PCH Conguration
PCH Devices
Press[Enter]forcongurationofadvanceditems.
PCH sSA
T
A Conguration
Press[Enter]forcongurationofadvanceditems.
PCH SA
T
A Conguration
Press[Enter]forcongurationofadvanceditems.
USB Conguration
Press[Enter]forcongurationofadvanceditems.
