Gigabyte MD80-TM0 User Manual

- 7 -
Item Code Description
1 CPU1_FAN CPU1 fan connector (for Secondary CPU)
2 SW_ID ID switch button
3 USB3_MLAN
BMC Management LAN port (top) / USB 3.0 ports
(bottom)
4 LAN1 LAN port #1
5 LAN2 LAN port #2
6 VGA VGA port
7 COM1 Serial port
8 P12V_AUX2 8 pin power connector (for secondary CPU)
9 PMBUS PMBus connector
10 DIMM_P1_G0 Channel 3 slot 0 (for secondary CPU)
11 DIMM_P1_G1 Channel 3 slot 1 (for secondary CPU)
12 DIMM_P1_G2 Channel 3 slot 2 (for secondary CPU)
13 DIMM_P1_H0 Channel 4 slot 0 (for secondary CPU)
14 DIMM_P1_H1 Channel 4 slot 1 (for secondary CPU)
15 DIMM_P1_H2 Channel 4 slot 2 (for secondary CPU)
16 CPU1 Intel LGA2011 Socket R (Secondary CPU)
17 ATX1 24 pin main power connector
18 DIMM_P0_A0 Channel 1 slot 0 (for primary CPU)
19 DIMM_P0_A1 Channel 1 slot 1 (for primary CPU)
20 DIMM_P0_A2 Channel 1 slot 2 (for primary CPU)
21 DIMM_P0_B0 Channel 2 slot 0 (for primary CPU)
22 DIMM_P0_B1 Channel 2 slot 1 (for primary CPU)
23 DIMM_P0_B2 Channel 2 slot 2 (for primary CPU)
24 P12V_AUX1 8 pin power connector (for primary CPU)
25 SYS_FAN5 System fan connector#5
26 CPU0 Intel LGA2011 Socket R (Primary CPU)
27 CPU0_FAN CPU0 fan connector (for Primary CPU)
28 DIMM_P0_D2 Channel 4 slot 2 (for primary CPU)
29 DIMM_P0_D1 Channel 4 slot 1 (for primary CPU)
30 DIMM_P0_D0 Channel 4 slot 0 (for primary CPU)
31 DIMM_P0_C2 Channel 3 slot 2 (for primary CPU)
32 DIMM_P0_C1 Channel 3 slot 1 (for primary CPU)
33 DIMM_P0_C0 Channel 3 slot 0 (for primary CPU)
34 SYS_FAN4 System fan connector#4
35 SYS_FAN3 System fan connector#3
36 MSAS_HD_1 Mini-SAS HD connector
37 IMR_KEY LSI RAID key header
38 SYS_FAN2 System fan connector#2
39 SYS_FAN1 System fan connector#1
40 SSATA_SGP sSATA SGPIO header
41 SATA_SGP SATA SGPIO header
42 SATA0/1/2/3/4/5 SATA 3 6Gb/s connectors
43 SW_RAID Intel Software RAID Key jumper
