Required Equipment and Materials Preliminary Installation Information
MDE-5427E Latitude
™
Installation Manual · July 2022 Page 4-1
4 – Preliminary Installation Information
Required Equipment and Materials
The following items are required to properly install the equipment:
• Anchor bolts.
• U-bolts for fastening piping to braces.
• Pit box cover plates. Use when required to adapt the unit to pre-exi
sting pit boxes.
• Lifting device (crane, backhoe, forklift, and so on) to move and lift
the pump/dispenser.
• Nylon slings (with a safety lift factor of 5) and screw-pin anchor
shackles to lift high hose
pump/dispenser.
• Breakaways, hoses, nozzles, and swivels.
• Barricades.
•Ladder.
• Any kits required for upgrading the unit to the customer’s requi
rements, such as hose
retrievers, and so on.
Preparing for Installation
To prepare for the installation, proceed as follows:
1 Read all instructions before you begin.
2 Follow all safety precautions:
• Barricade the area.
• Do not allow vehicles in the work area.
• Do not smoke or allow open flames in the work area.
• Do not use power tools in the work area.
• Do not allow unauthorized people into the work area.
• Wear eye protection during t
he installation.
• Ensure that there is no power su
pplied to the units until required, as per later installation
steps.
3 Use circuit breakers to turn off all power to pumps/dispensers and STPs. Multiple disconnects
may be required.
4 Check the following for proper installation, as recommended by other manufacturers:
• Emergency power cut off switch
• Circuit breakers
• STP control relay boxes - dispensers only (s
ee Note 3)
• Isolation relays - dispens
ers only (see Note 3)
• Conduit and wiring (see Note 1 on
page 4-2)
• Grounding
• Shear valves - dispensers only (see Notes 2 and 3 on page 4-2)
To Next Page
