GILBARCO VEEDER-ROOT Latitude LS-100 Installation Manual

Reference Contents Reference Information
MDE-5427E Latitude
™
Installation Manual · July 2022 Page 9-1
9 – Reference Information
Information in this section is provided for the installing contractor’s reference. The contractor
may or may not be required by individual contract to perform all or any of the requirements
outlined. However, all installations must conform to the requirements of this section.
Reference Contents
Section and Information Location
Electrical Requirements
page 9-2
Emergency Power Cutoff Switch
Circuit Breakers
page 9-2
STP Control Relay Boxes for Dispensers
STP Isolation Relays for Electronic Dispensers
page 9-3Wiring
Twisted-pair Wiring - Data Wire Lengths
Twisted-pair Conduit
page 9-4Twisted-pair Cable
Cable Ordering Information
Ethernet Cable
page 9-5
Ethernet Cable Installation Personnel and Procedures
Ethernet or CAT5 Cable Installation page 9-6
Grounding page 9-7
Sealing ‘Y’ Fittings page 9-8
Plumbing Requirements
page 9-9
Pipe Installation
Pipe Size
page 9-10
Pumps (Standard Flow)
Pumps (High Flow)
Dispensers (Standard Flow)
Dispensers (High Flow)
Dispensers (Latitude High Gallon)
Check Valves (Used on Pumps and Latitude Units only)
page 9-11
Shear Valves (Generally Used on Dispensers Only)
