GILBARCO VEEDER-ROOT Latitude LS-100 Installation Manual

Purpose Introduction
MDE-5427E Latitude
™
Installation Manual · July 2022 Page 1-1
1 – Introduction
Purpose
This manual contains step-by-step instructions for installing Gilbarco
®
LATITUDE™ pumps
and dispensers. The models include some differences in field wiring, calibration, parameter
setting, and hydraulic connections. This manual does not include site preparation instructions.
After the installation is complete, a Gilbarco-Authorized Service Contractor (ASC) must
commission the unit to activate the warranty. Proper completion of the checklist is required for
commissioning of the unit.
Read and follow all safety precautions outlined in “Important Safety Information” on
page 2-1 and save it in a readily accessible location.
The Latitude dispenser should not be used for biofuel blends of greater than 5%
biodiesel or greater than 10% ethanol without consulting Gilbarco.
IMPORTANT INFORMATION
Required Tools
The following tools are required for installing the Latitude pumps and dispensers:
• Flat-blade and Phillips
®
Screwdrivers
• 24-mm Nut Driver
• 17-mm Nut Driver
• Hex Key (Allen Key) Set - Metric
• Static Guard Wrist Strap
•Cutters
•Pliers
• Electronic Multimeter
Support Information
For technical assistance, contact Gilbarco Help Desk as follows:
• Middle East Africa (MEA): +9971566441341
• South-East Asia (SEA): +6596723261
• Sub-Saharan Africa (SSA): +27725308637
