Supply Connections for Single-phase Dispenser Wiring in Unit
MDE-5427E Latitude
Installation Manual · July 2022 Page 6-7
Supply Connections for Single-phase Dispenser
Figure 6-5: Connections for 1P MPD and Mono Base Dispenser
