GILBARCO VEEDER-ROOT Latitude LS-100 Installation Manual

Installing Breakaways, Hoses, Swivels, and Nozzles Units Without Hose Retractors
Page 7-2 MDE-5427E Latitude
™
Installation Manual · July 2022
Hose Torque 
Recommended torque when installing hoses is 40-50 N.m (30-35 ft-lbs). DO NOT OVER
TIGHTEN or damage to the nozzle could occur. Applicable when connecting hoses to the skid
tank, during internal repairs, and nozzle replacement.
CAUTION
Units Without Hose Retractors
To install breakaways, hoses, and swivels in pumps/dispensers without extended reach or hose
retractors, proceed as follows:
1 Install the breakaway whip hose to the pump/dispenser outlet casting (see Figure 7-1 on
page 7-3).
2 Install the listed breakaways to the whip hoses. Follow the breakaway manufacturer’s
instructions:
• Clean all threads.
• Place the sealant on male threads only
. Follow the sealant manufacturer’s instructions.
Note: Use only pipe sealant that is approved for use with petroleum products. Remove the
sealant
if it is found inside the hose or fittings. Clean off the excess sealant. Do not
use Teflon tape as it may damage the unit.
• Use a smooth-faced wrench to tighten all fittings securely
. Do not overtighten.
Note: Do not tighten the breakaway by twisting
the hose. This can damage the coupling.
3 Install the hose to the breakaway.
