Name Description Dimensions Initials Quantity
Shoulder washer 0.5 ±0.03 G 0.25 ÷ 0.50
Semi-shaft, trans.
side
13.75 +0.04 0 C 0.25 ÷ 0.50
Semi-shaft, fly-
wheel side
13.75 +0.04 0 D 0.25 ÷ 0.50
Spacer tool 40.64 H 0.25 ÷ 0.50
Casing 11.8 0 -0.35 B 0.20 ÷ 0.75
Shoulder washer 0.5 ±0.03 G 0.20 ÷ 0.75
Semi-shaft, trans.
side
13.75 +0.04 0 C 0.20 ÷ 0.75
Semi-shaft, fly-
wheel side
13.75 +0.04 0 D 0.20 ÷ 0.75
Spacer tool 40.64 H 0.20 ÷ 0.75
ROD SMALL END - ROLLER CASING -
TEST PROBE
Name Descrip
tion
Dimens
ions
Initials Quantit
y
Con-
necting
rod
Ø 17
+0.011
0.001
G 0.002 ÷
0.012
Roller
casing
Ø 2.5 0
0.007
F 0.002 ÷
0.012
Test
probe
Ø 12 +
0.005 +
0.001
H 0.002 ÷
0.012
FITTING CATEGORY ROD SMALL END -
ROLLER CASING - TEST PROBE
Name Descrip
tion
Dimens
ions
Initials Quantit
y
Rod
small
end
Cat. 3 Ø 17 + 0.011
+ 0.007
Rod
small
end
Cat. 2 Ø 17 + 0.007
+ 0.003
Rod
small
end
Cat. 1 Ø 17 +0.003
-0.001
Roller
casing
Cat. 1 Ø 2.5 0 -0.002
Runner Purejet Characteristics
CHAR - 9
