Girard Systems © 2005
PART NO. WHITE PART NO. BLACK PART NO. CREAM DESCRIPTION
1500031-
01 Main Housing Cover - 12'
1500032-01 Main Housing Cover - 14'
1500033-01 Main Housing Cover - 16'
1500034-01 Main Housing Cover - 18'
1500035-01 1500035-012 Main Housing Cover - 19' 8"
1500040-01 1500040-012 Main Housing Cover - 21' 8"
1500041-01 1500041-012 Main Housing Cover - 22í1 1"
1500076-02 Back Housing - 12'
1500077-02 Back Housing - 14'
1500078-02 Back Housing - 16'
1500079-02 Back Housing - 18'
1500080-02 Back Housing - 19í8"
1500085-02 Back Housing - 21' 8"
1500084-02 1500084-022 Back Housing - 22í1 1"
1500090-03 1500090-033 1500090-034 Main Housing End Plate - L.H.
1500091-03 1500091-033 1500091-034 Main Housing End Plate - R.H.
1500096-04 same same Back Housing Gutter 19' 8"
1500097-04 same same Back Housing Gutter 21' 8"
1500084-02 1500084-022 Black Housing Gutter 22í11î
15001 10-05 same same Screw For End Plates
15001 1 1-06 same same Mounting Bracket Slide Lock
15001 12-07 same same Mounting Bracket Slide Lock Allen Screw
15001 13-08 same same Mounting Bracket Middle - 4"
15001 14-08 same same Mounting Bracket End - 19"
15001 15-08 same same Mounting Bracket End - 11"
15001 16-08 same same Mounting Bracket End - 39"
1500120-12 same same Roller Tube - 12'
1500121-12 same same Roller Tube - 14'
1500122-12 same same Roller Tube - 16'
1500123-12 same same Roller Tube - 18'
1500127-12 same same Roller Tube - 19' 8"
1500128-12 same same Roller Tube - 21' 8"
1500129-12 Roller Tube 22í11î
1500141-13 same same Roller Tube Gudgeon Square - 78 mm
1500145-15 same same Roller Tube Support Bracket (Including Bolt & Screw)
1500150-16 same same Bolt and Screw for Roller Tube Support Bracket
1500151-17 same same Bolt and Washer for Motor Mount (includes 18)
1500152-17 same same Bolt and Washer for Crank Mount (includes 18 & 19)
1500154-20 same same Nut for Crank Mount Bolt
1500155-22 1500155-223 1500155-224
Shoulder Support L.H. - Complete
1500157-24 same same Bolt & Washer for Shoulder Support
1500158-25 same same Lock Plate for Shoulder Support Bolt
1500159-26 same same Nut for Pitch Adjustment Assembly
1500160-27 same same Pitch Adjust Assembly
1500161-28 same same End Plate for Arm Support
1500164-31 same same Screw End Plate Arm Support
1500164-32 1500164-323 1500164-324 Shoulder Support R.H. - Complete
1500165-33 same same Arm Connection Plate - L.H. (Incl. 35, 36, 37)
1500166-34 same same Arm Connection Plate -R.H. (Incl. 35, 36, 37)
1500167-35 same same Bushing for Arm Connection Plate
1500168-36 same same Pin for Arm Connection Plate
1500168-37 same same 70 mm Bolt for Shoulder
1500169-37 same same Bolt w/Nut and Washer for Arm to Shoulder Connect.
1500175-96 1500175-963 1500175-964 Lead Rail Connector - L.H. Complete
1500176-44 same same Arm to Lead Rail Set Screw & Washer - Series I
1500178-97 1500178-973 1500178-974 Lead Rail Connector - R.H. Complete
1500179-47 same same Arm to Lead Articulation Connector Pin
1500180-48 same same E Clip for Arm to Lead Rail Articulation Pin
*Number proceeding dash (-01) is indicative of actual part # on Exploded View
Parts List G2000 Automatic Awning/ G1500 Door Awning
