Girard Systems G2000 - Specifications; Awning Case Dimensions and Weight

53
Girard Systems © 2005
SPECIFICATION SHEET
G-2000/g-1500
Figure 36 Figure 37
g-2000 Awning case Dimensions (External) g-1500 Awning case Dimensions (External)
I. AWNING CASE
1. Height
a. 7-3/8" at mounting point
b 7-3/4" at front
2. Width
a. 5-1/4"
3. G-2000 Weight G-1500 Weight
a. 12'0" Awning - 116 lbs. a. 4'8" Awning -40 lbs.
b. 18'0" Awning - 172 lbs. b. 6'0" Awning -55 lbs.
c. 19'8" Awning - 188 lbs. c. 8'0" Awning -70 lbs.
d. 21'8" Awning - 208 lbs. d. 10'0" Awning - 85 lbs.
e. 22’11” Awning - 220lbs. e. 12'0" Awning -95 lbs.
4. Fabric
a. 100% Woven Acrylic
II. ROLLER TUBE
1. Diameter - 3"
