GIWEE C4OU-D36HR4-D01 - Ducted Unit

15
2.4 Ducted unit
Ducted IDU
CTA-
D07HR4-F101
CTA-
D09HR4-F101
CTA-
D12HR4-F101
CTA-
D18HR4-F102
Power supply
V/Ph/
Hz
220~240/1/50
220~240/1/50
220~240/1/50
220~240/1/50
Cooling
Capacity
Btu/h
7000
9000
12000
18000
kW
2.1
2.6
3.5
5.3
Input
W
20
20
30
55
Rated current
A
0.1
0.1
0.15
0.2
Heating
Capacity
Btu/h
8000
10000
13000
19000
kW
2.3
2.9
3.8
5.6
Input
W
20
20
30
55
Rated current
A
0.1
0.1
0.15
0.2
Fan
motor
Model
DR-310-27F-8
DR-310-27F-8
DR-310-27F-8
DR-310-55F-8
Type
DC
DC
DC
DC
Output
W
27
27
27
55
Speed(H/M/L)
r/min
850/640/550
850/640/550
850/640/550
1080/980/800
Indoor
coil
Number of rows
2
2
2
2
Tube pitch(a) × row
pitch(b)
mm
21*12.7
21*12.7
21*12.7
21*12.7
Fin type
Hydrophilic
Hydrophilic
Hydrophilic
Hydrophilic
Fin spacing
mm
1.4
1.4
1.4
1.4
Tube outside dia.
and type
mm
7
7
7
7
Inner screw
Inner screw
Inner screw
Inner screw
Coil size (W*D*H)
2*(515*27*146)
2*(515*27*146)
2*(515*27*146)
2*(715*38.1*14
7)
Number of circuits
4
4
4
4
Indoor air flow(Hi/Mi/Lo)
m
3
/h
550/410/340
550/410/340
550/410/340
800/700/600
Static Pressure
Pa
0-30
0-30
0-30
0-30
Indoor noise(Hi/Mi/Lo)
dB(A)
30/26/23
30/26/23
30/26/23
38/33/29
Sound power noise level
（Hi）
dB(A)
47
47
47
58
Net dimension(W×H×D)
mm
814×210×467
814×210×467
814×210×467
1010×210×467
packing dimension(W×H×D)
mm
910×240×510
910×240×510
910×240×510
1110×240×510
Net/Gross weight
kg
17/19.5
17/19.5
17/19.5
22.5/26
Liquid/Gas
mm
6.35/9.52
6.35/9.52
6.35/9.52
6.35/12.7
Drainage pipe
mm
DN25
DN25
DN25
DN25
Application area
m
2
10~15
12~18
16~23
23~34
Dehumidification
kg/h
0.5
0.6
0.84
1.27
