2.2 Wired controller
Long press “CHECK” button then press “UP” or “DOWN” button to check parameters.
No.
Description
Remark
1
Indoor unit capacity
Capacity= display data*10
2
Indoor unit demanded capacity
3
Amended demanded capacity by T4
4
Amended demanded capacity by T2
5
T1 room temperature
6
T2 evaporator temperature
7
T2B evaporator outlet temperature
8
T3 condenser temperature
9
T4 ambient temperature
10
T5/TP discharge temperature
11
EXV opening degree
Opening degree= display data*4
12
Compressor running frequency
13
AC voltage
Voltage=display data*4
2.3 One drive two outdoor unit
Press “Query” and “+” or “-” to turn to the page to find following information:
Code
Description
Remark
Fr
Running frequency
