GIWEE C4OU-D36HR4-D01 - Page 34

32
Model
Pipe size
Max. piping length
Max. piping height
Additional
refrigerant
Gas side
Liquid
Single
Total
IDU &
OUD
Between
IDUs
C2OU-D14HR4-A01
9.52*2
6.35*2
15m
30m
10m
5m
ForΦ
6.35(Pipe
length-
5)*15g/m,
forΦ
9.52(Pipe
length-
5)*20g/m
C2OU-D18HR4-A01
C3OU-D21HR4-C01
9.52*3
6.35*3
22.5
45
C3OU-D27HR4-C01
C4OU-D28HR4-D01
9.52*4
6.35*4
30
60
C4OU-D36HR4-D01
C5OU-D42HR4-D01
9.52*5
6.35*5
37.5
75
Indoor unit connection pipe diameter
Indoor unit capacity
Liquid side
Gas side
Accessories
7/9/12K
Φ6.35
Φ9.52
/
18K
Φ6.35
Φ12.7
One adapter
24K
Φ9.52
Φ15.88
Two adapters
