Rev.: 4, Print date: 2021-05-05
20
NL95
LIGHTS POSITION
1
PS
SB
1
2
3
4
5
6
7
8
9
10
13
12
14
15
1716
18
19
11
LIGHTS POSITION
1
PS
SB
1
2
3
4
5
6
7
8
9
10
13
12
14
15
1716
18
19
11
LIGHTS POSITION
2
1
1
2
When finished positioning all lights, tap on
to return back to configuration main screen
In this screen, each light is assigned with its position on selected mimic diagram, this is done by drag
and drop of light icon to required position.
Drag and drop light near the position
required on mimic
Light dragged and
moved to position
marked with +
Light dropped
MIMIC
MIMIC
PS
SB
PS
SB
PS SB PSSB
1
1
Tap to select mimic
2
Return back to configuration
main screen
2
Customized mimic is available on request
Please contact sales.
In this screen, it is necessary to select mimic drawing that will be used as background for
light arrangement.
