Glamox NL95 - NL95 Overview; System Description

Rev.: 4, Print date: 2021-05-05
1
NL95
1. Overview
- Color TFT display with touch panel
- Automatic switch-over to spare light
in case of main navigation light
malfunction
- Independent lights circuit connection
and light presentation on display.
- Switch on group of lights
by single button
- Switch off all lights by single button
- LED lights can be connected
- Modules interconnections via
original cables with connectors
1.1 Description
NL95 is a programmable control and monitoring system for navigation and signal lights. Built-in software
allows easy programming of lights configuration in main unit itself without requirement of external devices.
Modular construction makes it suitable for all ships / vessels types and sizes, with remote control feature it is
possible to integrate it with ship control system. The NL95 main unit is equipped with touch screen display, and
runs user-friendly, easy operating software.
It is available in 230 V ac, 115 V ac, or 24 V dc version depending on lights power supply. All versions
have dual power supply input (main and emergency) with automatic change-over.
NL95 continuously monitors status of lights that are switched on and light's circuitry by checking current
consumption. If current drops bellow threshold, alarm is activated and system automatically switches to
spare light (if exists), this provides more safety. Each light input is protected by double pole fuse.
Input modules are equipped with manual activation feature which allows operation even in case of
electronic failure.
NL95 maximum configuration controls up to 80 lights, i.e 30 double lights and 20 single or up to 50 single
lights.
NL95 tested and compatible with standard bulbs and Glamox / Aquasignal LED navigation lights series
60, 61, 65, 65Arctic, and series 75.
- Fully programmable lights presentation
properties (name, number, color,
shape, position, spare light existence)
POWER ON
FAILURE
F1
NL95 Touch screen Navigational Light Controller
