equipped with a 2.3 Amp power supply @ 28.5V DC nominal.
TECHNICAL SPECIFICATIONS
POWER SUPPLY AND CHARGER
PRIMARY SUPPLY
230 V +10% -15% V AC
MAINS ELECTRICAL FUSE
4 Amp - Surge protected (slow blow)
20 mm HRC
DC OUTPUT VOLTAGE
Maximum 28,5V DC
Minimum 19,7V DC
BATTERY CHARGER OUTPUT
27,5V DC nominal @ 20ºC
SECONDARY SUPPLY
24 V sealed lead acid batteries
Maximum capacity 2x 12 V 7 AH
Both fitted internally
Min. Voltage 21,7V DC (Vb min)
Max. Voltage 27,2V DC
Maximum Internal Resistance 1 Ohm
POWER SUPPLY RATING
2.3 Amps @ 28,5V DC nominal, comprising:
1.4 Amp used for internal electronic circuits and external ancillary
circuits: A maximum of 150 mA is available for each loop power.
Maximum of 65 mA for internal electronic circuits.
300 mA for auxiliary power supply outputs.
Under alarm conditions a maximum of 500 mA current available for
conventional sounder circuits.
POWER BUDGET QUIESCENT CONDITION
a - 60 mA internal circuits
b - 300 mA auxiliary supply outputs
c - 600 mA (4x150 mA) for analogue loop power
d - 1 Amp for battery charger
ALARM CONDITION
500 mA for conventional sounder circuits +a+b+c
AUX. POWER OUTPUT
28V DC 300 mA
MAX. RIPPLE VOLTAGE
400 mV peak-to-peak @ Maximum output loading
SENSOR / LOOP CIRCUITS
Max. number of devices per loop: 188
(125 individually addressed + 63 auxiliary)
Supports analogue addressable devices over a 2 wire combined power and digital data
transmission loop
Maximum Loop current :150 mA
Loop short circuit (trip) current: 900 mA
Maximum recommended loop length is 1.2 km with 1.5 mm² wire cross-section
Maximum cable capacitance 120 pF/m
Minimum cable cross-section: 0.5 mm²
Maximum cable cross-section: 2.5 mm²
CONVENTIONAL SOUNDER CIRCUITS
2 individually programmed. Both circuits current limited and monitored for both open and
short circuit fault conditions.
10k Ohm E.O.L. resistors are used.
Maximum current rating per circuit 500 mA.
AUXILIARY RELAY OUTPUTS
2 voltage free changeover relay outputs used for fire indication.
1 voltage free relay output for fault indication. Remains energized (normally closed) under
normal condition and de-energized when any fault condition appears on the system.
Maximum current rating for each relay contact 2A @ 30V DC resistive / 0.5 @ 120V AC
resistive.
