Global Fire Gekko - Repeater Specifications

Global Fire Equipment // globalfire.pt
ma_gekko_01_010002_en_190522
OPERATING TEMPERATURE
-10ºC to + 50ºC
RELATIVE HUMIDITY
85% (non-condensing)
DIMENSIONS
273 (W) x 404 (H) x 107 (D) mm
WEIGHT
Empty: 1.6 Kg
Including sealed lead acid batteries: 2 x 12 V 7 AH - 7.0 Kg
REPEATER
SUPPLY VOLTAGE
24V DC nominal
QUIESCENT CURRENT MAX.
65 mA
DIMENSIONS
340 (W) x 370 (H) x 125 (D) mm
WARNING:
In case of a short circuit or interruption of the analogue detection loop, only a maximum
of 32 detectors or call points (per loop) can be prevented, at any given time,
of transmitting a fire alarm. In order to assure compliance with EN54-2 clause 12.5.2 loop isolators
have to be installed every 32 devices in the loop.
48
