Section 3 Product Information
3-4
3.4. Vacuum Pump and Canister System Specications
The Vacuum Pump is a 110-120V, 3.2/1.7 A, 60 Hz, thermally protected, piston-type pump. The pump will draw
down to a maximum of 25 inches (635 mm) of mercury. Unrestricted air ow is 4.4 cubic feet (125 liters) per
minute. A disposable canister with overll protection collects contaminates. There is a hydrophobic lter in the
vacuum line to protect the pump.
High Vacuum/High Flow: 125L/min.@ 0 in Hg, 10L/min. @ 25 in Hg.
3.5. Pressure Pump Specications
The pressure pump is a 115 4.2A, 60 Hz, thermally protected, piston-type compressor. The maximum
continuous or intermittent pressure developed by the pump is 100 psig, however the regulator will only
permit control of this pressure between 0 and 60 psig. The pump ships from the factory set to 20 psig (1.4
bar). Normally, the regulator should be adjusted for approximately 10 psig (0.7 bar) (see paragraph 4.8.3)
A dampener stores a small charge of air pressure so that a steady air ow is maintained consistently at the
output nozzle.
3.6. S 7401355 Sunction/Pressure Foot Switch (Optional) Specications
The Foot Switch has black PVC twin bellows and a strong, low-prole standard grey ABS base. The base has
non-skid feet and is weighted to reduce movement. The Foot Switch is pneumatically operated and electrically
isolated. The Foot Switch provides convenient ON/OFF control of the suction and/or air pump and provides
hands-free operation.
CAUTION
!
Equipment intended to be used on at plane. Using on inclined plane may reduce capacity
of collection canister.
