13
INSTALLATION & COMMISSIONING MANUAL - REVISION 1.0 - 19.FEB.2007
J-NET-INT-FO:
FIBRE OPTIC INTERFACE
J-NET-INT-485-NEW
INTERFACE FOR RS485
COMMUNICATION
J -SIM:UNIOR
JUNiOr SIM CARD
J-NET-INT-TCP/IP
INTERFACE FOR TCP/IP
COMMUNICATION
Typical cable form (one end)
VIEW FROM TOP
THROUGHOUT THE MANUAL,
THE PIN ON THE 5 WAY MOLEX
INDICATES WHICH PIN IS
RED
Nº1
VIEW FROM FRONT
MALE FEMALE
NOTE:
Identifying Components
OVERVIEW
NOTE:
Junior can only be networked with
repeater panels.
