TECHNICAL
SPECIFICATIONS
Weight:
Operating temperature:
Relative Humidity:
Conventional Sounder Circuits:
Auxiliary Relay Outputs:
Sensor / Loop Circuits:
Primary Supply:
Input Operating Voltage:
Mains electrical fuse:
Empty: 1.6 Kg
Including sealed lead acid batteries:
2 x 12 V 7 AH 7.0 Kg
0ºC to + 40ºC
85% (non-condensing)
2 individually programmed. Both circuits current limited and monitored for
both open and short circuit fault conditions. 10k Ohm E.O.L. resistors are
used.
Maximum current rating per circuit 400mA.
2 voltage free changeover relay outputs used for fire indication.
1 voltage free relay output for fault indication. Remains energised
(normally closed) under normal condition and de-energises when any fault
condition appears on the system.
Maximum current rating for each relay contact 1A @ 50 V AC/DC resistive.
1 loop model.
Max. number of devices per loop: 125
Supports analogue addressable devices over a 2 wire combined power and
digital data transmission loop.
Maximum Loop current :250mA
Loop short circuit (trip) current: 900mA
Maximum recommended loop length is 1 Km with 1.5 mm2 wire cross-
section. Maximum cable capacitance 120 pF/m.
Minimum cable cross-section: 0.5 mm2
Maximum cable cross-section: 2.5 mm2
85-264 V AC.
4 Amp - Surge protected (slow blow)
20 mm HRC
Fuse located on electrical mains connector TB, placed above the PSU inside
the box.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Please note that these specifications apply to the Junior Analogue Addressable panel, 1 loop model,
equipped with a 1.7 Amp power supply @ 28.5V DC nominal.
Power Supply and Charger
WARNING: In case of a short circuit or interruption of the analogue detection loop, only a
maximum of 32 detectors or call points (per loop) can be prevented, at any given time, of
transmitting a fire alarm. In order to assure compliance with this clause, loop isolators
have to be installed every 32 devices in the loop .
