Global JUNIOR V4 - Advanced Functionality; Programming Functions Overview and Usage

CONTENTS
39
1 Review Historic Log
1-1 Display Historic Log
1-3 Clear Historic Log
1-5 Read/Clear Autostart Count
3 Zones - Disable & Assign
3-1 Disable Zones
3-2 Assign Sounder Groups to Zones
3-3 Assign I/O Groups to Zones
3-4 Assign Zone to Device
3-5 Zone Sounder Delay Set-up
4 Sounders - Disable & Assign
4-1 Sounder Configuration
4-2 Configure Sounder Groups
4-3 Disable Sounders
4-4 Assign Sounder Group to Device
4-5 Inhibit Sounders for Device
4-6 Sounder Delay Set-up
4-7 Override Sounder Delays
5 Input/Output - Disable & Assign
5-1 Configure I/O Groups
5-2 Select Fault I/O Group
5-3 Assign I/O Group to Device
5-4 Inhibit I/O for Device
5-5 I/O Unit Action upon Evacuate
5-6 I/O Unit Delay or Immediate
5-7 I/O Delay Set-up
6 Device Set-up
6-1 General
6-1-1 Disable Loops
6-1-2 Device Disable
6-1-3 Set Selective Disablement
6-1-4 Set Device Reporting Details
6-1-5 Set Immediate Evacuate for Device
6-1-6 Device Activation Overrides Delays
6-1-7 Inhibit Auxiliary Relays
6-1-8 Global Sensitivity Set-up
6-1-9 Configure Timed Sensitivity
6-2 Other Device Options
6-2-1 Select Device Heat Grade
6-2-2 Select Device Smoke Sensitivity
6-3 Discovery Specific - Functions only available for
panels programmed to use Apollo Discovery Protocol
6-3-1 Select Device Sensitivity Mode
6-3-2 Flashing Leds On/ Off
6-3-3 Disable Specific Flashing Leds
6-3-4 Re-calibrate All Devices
6-3-5 Check for Devices Needing Service
6-3-6 Read Data Stored in Device
6-3-7 Write Data Stored in Device
6-4 Automatic Address Setting (SAM)
6-4-1 Activate ASET Mode (SAM)
6-4-2 Clear Loop
6-4-3 Clear Device
7 Monitor Device Counts & Test
7-1 Device Count, Type & Value
7-2 Test Sounders
7-3 Sounders on Test Activation
7-4 Test Zones
7-6 Light LED on device
8 General
8-1 Time/Date & Timers
8-1-1 Set Date & Time
8-1-2 Define Day & Night
8-1-3 Delays Off at Night
8-1-4 Configure Evacuate Timer
8-1-5 Device Starts Evacuate Timer
8-2 Special Features Set-up
8-2-1 Two Devices to Evacuate
8-2-2 Call Points to Evacuate
8-3 Memory - BEWARE, ENGINEERS ONLY
8-3-1 Clear Customer Flash Memory
8-3-2 Clear Non-Volatile RAM
8-3-3 Calculate Customer Flash Checksum
8-3-4 Calculate Program Flash Checksum
8-4 Other Features
8-4-1 Active/Installation Mode
8-4-2 Upload/Download Link to PC
8-4-4 Set User Access Code
8-4-5 Set User Functions
8-4-6 Select language
8-4-8 Set Installer Access Code
Programming Functions General
CONTENTS
ADVANCED
FUNCTIONALITY
INSTALLATION & COMMISSIONING MANUAL - REVISION 1.0 - 19.FEB.2007
