Global JUNIOR V4 - System Schematic, Components, and Specifications

7
INSTALLATION & COMMISSIONING MANUAL - REVISION 1.0 - 19.FEB.2007
OVERVIEW
Typical System Schematic
ISO ISOOPT ZMU TMP
BGU LSM
I/O
+
24 V
CON
DET
CON
DET
CON
DET
EOL
4K7
ION
EOL
10K
EOL
SNDSNDSND
ALL AUX RELAYS RATED AT
50V AC/DC 1 AMP RESISTIVE
DATA LOOP CONNECTOR MPX: MULTIPLEXED ZONE LED CONNECTOR
AUXILIARY
POWER SUPPLY
OUTPUT
CLASS CHANGE
OR
REMOTE EVAC.
REMOTE
DISABLEMENT
OF SELECTED
DETECTORS
VOLTAGE FREE
NORMALLY OPEN CONTACTS
NON-LATCHING ACTION
PC Loader
DB9 Female
Connector
Loop 2
Connections
