NOTE:
Specific devices can be set not to activate I/O (including Common I/O) - function 5-4
Inhibit I/O for Device. .
46
INSTALLATION & COMMISSIONING MANUAL - REVISION 1.0 - 19.FEB.2007
CONTENTS
5 Input/Output - Disable & Assign
Input/Output Analogue Loop device management.
5-1 Configure I/O Groups
Allows an I/O Group to be established. The I/O Group can then be used for fire or fault reporting. 512
I/O Groups can be defined.
First select the Group number then assign the I/O loop addresses.
Each I/O Group can have up to 32 I/O units. (256 for the Common I/O Group)(Group 512).
I/O Group 512 is the Common I/O group. The Common I/O Group is always activated when a fire
occurs.
When a fire occurs all the I/O information for the detector in fire is combined: the device I/O Group is
combined with the Common I/O Group and the four ‘first fire’ Zone I/O Groups.
When a subsequent fire occurs in the same Zone the ‘second fire’ Zone I/O group is activated.
Upon a fire the I/O operations are cumulative.
5-2 Select Fault I/O Group
Allows a specified I/O group to be activated if a fault condition occurs.
It is not recommended to use the same I/O group for fire and fault reporting.
