NOTE:
An evacuate is not considered as an automatically detected fire event.
Delays will only occur if front panel ACTIVE DELAYS button has been set to on.
Specific I/O modules (function 5-6) and specific detectors (function 6-1-6) can be set to override
this delay. .
NOTE:
NOTE:
When a fire occurs all the I/O information for the detector in fire is combined: the device I/O
Group is combined with the Common I/O Group and the four ‘first fire’ Zone I/O Groups.
47
INSTALLATION & COMMISSIONING MANUAL - REVISION 1.0 - 19.FEB.2007
CONTENTS
5-3 Assign I/O Group to Device
Allows an I/O Group to be assigned to a detector. When the detector goes into alarm then the assigned
I/O Group will be activated.
This function can be used to assign an I/O module (input) to activate an I/O Group output. The I/O
Group output could be on the same I/O module, another I/O module or a group of I/O modules.
5-4 Inhibit I/O for Device
Allows a device to be set so that it does not operate certain I/O Groups.
The options are:
COMMON The Common I/O Group (512) is not activated when the device detects fire
ZONAL The Zone I/O Group for the device is not activated when the device detects fire
ALL No I/O Groups are activated when the device detects fire
COMMON or ZONAL inhibits will not inhibit the I/O Group directly assigned to a device (function 5-3
Assign I/O Group to Device) if that device detects fire.
5-5 I/O Unit Action upon Evacuate
Allows you to define how an I/O module will perform when an evacuate is signaled. By default an I/O
module will not activate unless it has been assigned to an I/O Group than has been activated.
5-6 I/O Unit Delay or Immediate
Allows a specific I/O module to be set so that it activates immediately even if the rest of the I/O is set to be
activated after a delay.
5-7 I/O Delay Set-up
Allows the I/O (output) delay to be set. This delay applies to all I/O module outputs.
The maximum delay that is allowed is 10 minutes.
There is only one I/O timer so once it has expired events activating further delayed I/O groups will cause
immediate I/O operation.
