NOTE:
40
INSTALLATION & COMMISSIONING MANUAL - REVISION 1.0 - 19.FEB.2007
Keys To Use Within Functions
Most functions use some or all of the following keys:
pqare used to browse through items
u is often used to change fields (move the cursor). It will also be used, when required to toggle between
Loops 1 and 2.
ENTER is used to select items and store changes
ESC is used to abort changes and exit
The cursor is often shown to highlight the item that is being changed.
Help
Where possible, help is displayed automatically.
.
.
.
.
.
.
.
.
.
General
Because of the flexibility and functionality of this panel it can sometimes be quite hard to establish your
desired configuration. Zone, device and group events interact as do the various timers.
If the system does not seem to operate as intended please take your time and review the various sections in
this manual. Some settings need the front panel buttons to be activated whilst others can be inhibited for
specific devices.
The basic functionality of the panel is readily available and the fire alarm system will be operational just by
supplying it with electrical power. Exercising cause and effect capability is what this section is all about.
The best way to become familiar with all the programming facilities of this panel will be a hands-on
approach aided closely by this manual.
CONTENTS
If a fire occurs whilst the panel is in programming mode then programming mode will
automatically be exited. If a fault occurs whilst in programming mode the fault will be
reported but it is necessary to manually exit programming mode to read the fault details on
the LCD.
.
CONTENTS
ADVANCED
FUNCTIONALITY
