GLP impression X5 - Page 71

German Light Products® DMX MODE 5
Rev. 20220720-01 71
DMX Mode 5: Multipix compressed
71 DMX Channels
Channel
Command
DMX
range
Percent
%
Default
DMX
Fade
Main Module Basic control
1
Pan coarse
Pan left → right
0
65535
0
100
32768
Fade
2
Pan fine
3
Tilt coarse
Tilt front → back
0
65535
0
100
32768
Fade
4
Tilt fine
5
Intensity coarse
Intensity 0 → 100%
0
65535
0
100
0
Fade
6
Intensity fine
7
Shutter
Closed
0
4
0
1.6
0
Snap
Single flash if value changed within
the range 005 → 009
5
9
2.0
3.5
Fade
Pulse slow → fast
10
39
3.9
15.3
Fade
Pulse opening slow → fast
40
69
15.7
27.1
Fade
Pulse closing slow → fast
70
99
27.5
38.8
Fade
Double flash slow → fast
100
129
39.2
50.6
Fade
Strobe random pixel slow → fast
130
159
51.0
62.4
Fade
Strobe random all slow → fast
160
199
62.7
78.0
Fade
Strobe sync all pixel slow → fast
200
250
78.4
98.0
Fade
Open
251
255
98.4
100
Snap
8
Zoom
Zoom narrow → wide
0
255
0
100
0
Snap
9
Control/Settings
See ’Control / Settings channel’ on page 71
10
Accessory 1
Effect parameter 1
0
255
0
100
0
Snap
11
Accessory 2
Effect parameter 2
0
255
0
100
0
Snap
12
CTC (Color
Temperature
Control)
Open, selected white point
0
9
0
3.5
0
Snap
Fade through color temperatures of
1000 K to 2500 K stepless
(interpolation)
11
11
4.3
45.9
12
254
4.7
49.8
Fade
255
255
100
53.7
Snap
13
CQC (Color Quality
Control) /
Saturation
HQ (high quality), saturated color
0
9
0
3.5
0
Snap
Crossfade
10
117
3.9
45.9
Fade
HQ (high quality), unsaturated color
118
127
46.3
49.8
Snap
HO (high output), unsaturated color
128
137
50.2
53.7
Crossfade
138
245
54.1
96.1
Fade
HO (high output), saturated color
246
255
96.5
100
Snap
15
Red, pixel 01
Intensity 0 → 100%
0
255
0
100
0
Fade
16
Green, pixel 01
Intensity 0 → 100%
0
255
0
100
0
Fade
17
Blue, pixel 01
Intensity 0 → 100%
0
255
0
100
0
Fade
18
Red, pixel 02
Intensity 0 → 100%
0
255
0
100
0
Fade
19
Green, pixel 02
Intensity 0 → 100%
0
255
0
100
0
Fade
20
Blue, pixel 02
Intensity 0 → 100%
0
255
0
100
0
Fade
21
Red, pixel 03
Intensity 0 → 100%
0
255
0
100
0
Fade
22
Green, pixel 03
Intensity 0 → 100%
0
255
0
100
0
Fade
23
Blue, pixel 03
Intensity 0 → 100%
0
255
0
100
0
Fade
24
Red, pixel 04
Intensity 0 → 100%
0
255
0
100
0
Fade
25
Green, pixel 04
Intensity 0 → 100%
0
255
0
100
0
Fade
26
Blue, pixel 04
Intensity 0 → 100%
0
255
0
100
0
Fade
27
Red, pixel 05
Intensity 0 → 100%
0
255
0
100
0
Fade
28
Green, pixel 05
Intensity 0 → 100%
0
255
0
100
0
Fade
29
Blue, pixel 05
Intensity 0 → 100%
0
255
0
100
0
Fade
