XRS-330C
76
Transmitter
R F Output: 5 watts
Spurious Emission: < - 70 dBc
Frequency Error: < ± 1.5 kHz
Modulation: FM
Maximum Deviation: < ± 2.5 kHz at + 20 Db AF limiting.
Transmit Frequency
Response:
+6 dB per octave 300 Hz to 3 kHz +
1 . 3 dB.
Demodulated Audio
Signal to Noise:
>45 dB unweighted
Current Consumption: 1.7 amps with 50 Ohms termination.
Receiver
Intermediate
Frequencies:
38.85 MHz, 450 kHz
Sensitivity: -122 dBm for 12 dB SINAD unweighted
Selectivity: -6 dB at ± 3.5 kHz, -60 dB at ± 12.5 kHz
Intermodulation
Immunity:
-72 dB
Blocking Immunity: -98 dB
Spurious Response
Immunity
70 dB
Audio Output Power: 3 watts average into 4 Ohms
Audio Signal to Noise: >45 dB unweighted
Receive Frequency
Response
-6 dB/Octave de-emphasis 300 Hz to 3 kHz +1 -3 dB.
Current Consumption: <175 mA muted, 750 mA full volume.
Conducted Spurious
Emmission
<70 dBm
