13-11
OPERATOR MAINTENANCEUSER HANDBOOK
COTTON FILTER
HOUSING
COTTON FILTER
(Part No. 10077)
PENCIL
(OR SIMILAR)
Fig. 13.8 Cotton Filter Removal
4) If the cotton lter is contaminated or damaged, replace the
lter (Part No.10077 - Box of 10).
5) Before attaching the lter housing to the hydrophobic lter
bulb, check the washer for signs of damage. If damaged, it
must be replaced with a new washer (Part No.12379).
6) Hold the hydrophobic lter bulb then attach lter housing to
the hydrophobic lter bulb by turning in a clockwise direction
until secure. See Fig. 13.7.
Note: Care must be taken not to overtighten the housing.
7) Before attaching the probe to the cotton lter housing,
check the probe washer for signs of damage. If
damaged, it must be replaced with a new probe washer
(Part No.12379).
8) Attach probe to the cotton lter by turning in a clockwise
direction until secure. See Fig. 13.7.
Note: Care must be taken not to overtighten the probe.
