9-6
SNIFFER MODEUSER HANDBOOK
9.6.1 Select Audible / Visual Ticker (Geiger)
Combination Option
The Ticker (Geiger) function can be set for audible and visual
combination options as follows: Both ON; Audible OFF / Visual ON;
Both OFF; Both ON; etc.
To select required audible / visual combination option:
• Press and hold both UP and DOWN buttons.
• Repeat operation to cycle through combination options.
Red LED's - Pair 1
Red LED's
PPM Level
Pair 7
Pair 6
Pair 5
Pair 4
Pair 3
Pair 2
Pair 1 100
Pair 8
Pair 2 200
Pair 3 300
Pair 4 400
Red LED's
PPM Level
Pair 5 500
Pair 6 600
Pair 7 700
Pair 8
800 - 1000
Fig. 9.3 Ticker (Geiger) LED Illumination
