12-8
ALARMSUSER HANDBOOK
The following Table 12.2 shows the alarm options available in the
Leak Test and Conned Space Modes.
LEAK TEST CSM
FLAM CO H2S O2 FLAM CO H2S O2
WARNING
20
Hi
Hi Hi 20 35 15 23
STEL 200 10
LTEL 30 5
Lo
Lo Lo
19.5
Table. 12.2 Alarm Options
Note:
1. Where there is a square with a number, it means that the GMI
default is to have these alarms active at the gas concentration
shown by the number.
2. Where there is a square without a number, it means that
this alarm option is available should the user wish to have it
activated.
3. The alarm concentrations must, if active, be the same level
in both modes.
