goBILDA Master FTC Kit - Page 5

5
Basic Bot Guide
Image Qty. # Part Name
x2
1121
Series Low-Side U-Channel (5 Hole, 144mm Length)
x2
1121
Series Low-Side U-Channel (17 Hole, 432mm Length)
x2
1123
Series Pattern Plate (1 x 1 Hole, 48 x 48mm)
x2
1123
Series Pattern Plate (1 x 3 Hole, 48 x 96mm)
x2
1123
Series Pattern Plate (1 x 5 Hole, 48 x 144mm)
x2
1123
Series Pattern Plate (1 x 9 Hole, 48 x 240mm)
x4
1309
Series Sonic Hub (6mm D-Bore)
x22*
1500
Series Plastic Spacer (6mm ID x 8mm OD, 1mm Thickness)
x2
1504
Series 32mm OD Pattern Spacer (4mm Length)
x6
1611
Series Flanged Ball Bearing (6mm ID x 14mm OD, 5mm Thickness)
x2
2101
Series Stainless Steel D-Shaft (6mm Diameter, 100mm Length)
x6
2800
Series Zinc-Plated Steel Socket Head Screw (M4 x 0.7mm, 6mm Length)
x48
2800
Series Zinc-Plated Steel Socket Head Screw (M4 x 0.7mm, 8mm Length)
x12
2800
Series Zinc-Plated Steel Socket Head Screw (M4 x 0.7mm, 10mm Length)
