goBILDA Master FTC Kit - Page 6

6
Basic Bot Guide
Image Qty. # Part Name
x30*
2800
Series Zinc-Plated Steel Socket Head Screw (M4 x 0.7mm, 12mm Length)
x18
2800
Series Zinc-Plated Steel Socket Head Screw (M4 x 0.7mm, 16mm Length)
x2
2800
Series Zinc-Plated Steel Socket Head Screw (M4 x 0.7mm, 60mm Length)
x16
2801
Series Zinc-Plated Steel Washer (4mm ID x 8mm OD)
x52*
2812
Series Zinc-Plated Steel Nylon-Insert Locknut (M4 x0.7mm, 7mm Hex)
x4*
2906
Series Aluminum Set Screw Collar (6mm Bore, 8mm Length)
x2
3601
Series Rhino Wheel (14mm Bore, 96mm Diameter)
x2
3604
Series Omni Wheel (14mm Bore, 96mm Diameter)
x2
5202
Series Yellow Jacket Planetary Gear Motor (13.7:1 Ratio, 435RPM, 3.3 - 5V
Encoder)
x6
N/A
Zip Tie (100mm Length, Black)
x1
REV
REV Expansion Hub (NOT INCLUDED IN KIT)
x1
REV
REV Switch Assembly (NOT INCLUDED IN KIT)
*Indicates that a dierent quantity is required if the Alternate Assembly (Step 16) is built
