Godex RT700i SERIES User Manual

37
3 Setting and Control for Operation Panel
034
Operation Panel
Status
Type
Beeps
Description
Solution
File Error 2 x 2 beeps
The memory is full. The printer
prints the message "File System full
".
Delete unnecessary data or install
additional memory.
Unable to find file. The printer
prints the message "File Name not
found"
Use the "~X4" command to print
all files. Then check whether the
files exist and whether the names
are correct.
A file of the same name already
exists. The printer prints the
message "Duplicate Name".
Change the name of the file and
try storing it again.

Godex RT700i SERIES Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max Print Width	4.09" (104 mm)
Print Resolution	203 dpi
Print Speed	7 IPS (177.8 mm/s)
Max Print Length	1727 mm (68")
Memory	8 MB Flash, 16 MB SDRAM
Interface	USB 2.0, Serial RS-232, Ethernet
Processor	32-bit RISC CPU
Sensors	Gap transmissive sensor, Black mark reflective sensor
Power	AC 100-240V, 50/60Hz
Label Width	10 - 110 mm
Label Thickness	0.06 - 0.25 mm (2.36 - 9.84 mil)
Roll Outer Diameter	127 mm (5")
Core Diameter	25.4 mm (1")
Dimensions	285 mm (W) x 171 mm (H) x 226 mm (D)
Weight	5.5 lbs (2.5 Kg)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
Operating Humidity	30% - 85% non-condensing
Certifications	CE, FCC, RoHS
