Godex RT700i SERIES User Manual

3 Printer Setting and Control
3.9 Dump Mode Begin
For make sure provide us correct information for check what commands sentfrom the PC or software, please following below
steps,
STEP 1, Let the printer enter Dump Mode
For Desktop printer (RT200i / RT700i series, with LCD)
Just press and hold the key until LCD Display shows “DUMP MODE ”, then release the key.
STEP 2. Make sure pinter ready for print a label
STEP 3. Send a label or commands which met problem to the printer
STEP 4. Printer will print out a label with letters and numbers, please take a picture on them and send us by email.
To cancel (get out of) the Dump Mode, please press the FEED key, and then the printer will
automatically print “OUT OF DUMP MODE.” This indicates that the printer is back to the standby mode.
40

Godex RT700i SERIES Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max Print Width	4.09" (104 mm)
Print Resolution	203 dpi
Print Speed	7 IPS (177.8 mm/s)
Max Print Length	1727 mm (68")
Memory	8 MB Flash, 16 MB SDRAM
Interface	USB 2.0, Serial RS-232, Ethernet
Processor	32-bit RISC CPU
Sensors	Gap transmissive sensor, Black mark reflective sensor
Power	AC 100-240V, 50/60Hz
Label Width	10 - 110 mm
Label Thickness	0.06 - 0.25 mm (2.36 - 9.84 mil)
Roll Outer Diameter	127 mm (5")
Core Diameter	25.4 mm (1")
Dimensions	285 mm (W) x 171 mm (H) x 226 mm (D)
Weight	5.5 lbs (2.5 Kg)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
Operating Humidity	30% - 85% non-condensing
Certifications	CE, FCC, RoHS
