Godex RT700i SERIES User Manual

WiFi Printer Server Module Installation - For
RT700iW/ RT730iW
RT700i/RT730i USER MANUAL
APPENDIX
**** Please prevent below incorrect installation,
when installing WiFi Printer Server Module.
Note
1.1 WiFi Printer Server Module Installation
2. Remove the stickers and
paste to the cover.
1. Follow the indicator to insert the module.
1
2
3.
Close the bottom base cover,
the installation finished.
3
Does not parallel with mainboard.

Godex RT700i SERIES Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max Print Width	4.09" (104 mm)
Print Resolution	203 dpi
Print Speed	7 IPS (177.8 mm/s)
Max Print Length	1727 mm (68")
Memory	8 MB Flash, 16 MB SDRAM
Interface	USB 2.0, Serial RS-232, Ethernet
Processor	32-bit RISC CPU
Sensors	Gap transmissive sensor, Black mark reflective sensor
Power	AC 100-240V, 50/60Hz
Label Width	10 - 110 mm
Label Thickness	0.06 - 0.25 mm (2.36 - 9.84 mil)
Roll Outer Diameter	127 mm (5")
Core Diameter	25.4 mm (1")
Dimensions	285 mm (W) x 171 mm (H) x 226 mm (D)
Weight	5.5 lbs (2.5 Kg)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
Operating Humidity	30% - 85% non-condensing
Certifications	CE, FCC, RoHS
