10 TECHNICAL DATA
10.1 HS80, HS100, HS100-SG, HS103, HS150, HS150V & HS150V-SG
Pumps
PUMP HS80 HS100 HS100-SG
HS103 HS150
HS150V
HS150V-SG
Rotation
ACW looking at
impeller from
suction end
See Note 1
ACW looking at impeller from suction end
Max pump
speed
rpm
2600 2400 2400 2200 1500 2400
Max head
m (ft)
25 (82)
35 (115)
52
20 (66)
33 (108)
Max flow
m
3
/hr
(Imp.
gpm)
80 (293) 200 (733) 175 230 400 (1466) 432 (1590)
Nominal solids
capacity
Ø mm (“)
40 (1.575) 45 (1.77) 75 65 (2.56) 127 (5)
Impeller
clearance (front
and rear)
mm (“)
0.50 – 0.63 (0.020 – 0.025)
0.4 – 0.5
(0.015 – 0.020)
Rear 0.50 – 0.63
(0.020 – 0.025)
Front
N/A
Impeller screw
(nut) torque
Nm
(lbs.ft)
98 (72) 197 (145)
Mechanical
seal setting
dimension
mm (ins)
N/A N/A N/A
Mechanical
seal oil
N/A. Seal is fed
from hydraulic
system
Any SAE 20/20 or Biopus 46 Biodegradeable
Bearing bracket
oil
N/A SAE 20/20
Discharge
connection
Female 3”NPT
or 3”BSP
Female
4”NPT or
4”BSP
Flanged 4”
ASA150 or
4” BS10
Table D
Female
4”NPT or
4”BSP
Female 6”NPT
or 6”BSP
150V: -Female 6”NPT
150V-SG: -
Flanged 6”
ASA150
Bearing bracket
leakage
connection size
¼”BSPT female
3/4” NPSM for ASA150 or NPT units;
3/8” BSPT female for BS10 or BSP units
Hydraulic motor interface
Flange
SAE ‘A’ 2 bolt
SAE ‘B’ 2 bolt
SAE ‘C’ 4 bolt
Shaft
1 1/8” x 24 straight
sided serrations to
BS2059: 1953
SAE ‘A’ spline
Ø15.5
9 teeth 16/32 DP
SAE spline
Ø21 13 teeth
16/32 DP
SAE spline 1 ¼” 14
teeth
12/24 DP
Xylem Dewatering Solutions supplied motors
Drive pressure
bar (psi)
280 (4060)
250 (3625)
Flow & Return
connection size
(supplied with quick
release couplings
on 8022, 10022 &
10022)
½”BSPT female 3/4”BSPT female
Bearing
leakage
connection size
(supplied with quick
release couplings
on 8022, 1002 &
15022)
¼”BSPT female 3/8”BSPT female
Pump leakage
connection size
N/A N/A
Hydraulic oil
Fluid conforming to ISO 32-46
Standard Biodegradeable
Shell Tellus Oil 27 Shell Naturelle Fluid HF-E 32
Shell Naturelle Fluid HF-E 46
Texaco Rando HD 32 or 46 Texaco Hydra 46
Texaco Rando HDZ 32 or 46 Terrasolve Envirologic 132
Max flow
l/min @
rpm
12.0 @ 2600 36 @ 2300 55.9 @ 1670 100@2000
NOTES. 1.Exercise particular caution with these units. Early 10022 are CW looking at impeller from suction end; later
units are ACW.
