Page #119 background imageLoading...
Page #119 background image
SmartBox
®
1 / SmartBox
®
2 / SmartBox
®
3
n.º de artículo 28 100 73 c 19 / 20
DATOS TÉCNICOS
Indicador
Operación Tipo 1.B ( según EN 60730-1)
Grado de contaminación 2 ( según EN 60730-1)
Nominal-tensión transitoria 4000 V
Tensión de abastecimiento
230 V AC 50 Hz
Energía absorbida
max. 2 VA
Medición de entrada
4 a 20 mA; Uo = 20 V
Salida relé
SmartBox
®
2 + 3
Tensión de conexión
max. 250 V AC
Corriente de conmutación
max. 3,5 A
Medidas Al x An x P in [mm]
194 x 130 x 65 mm
Modo de protección
según EN 60529
IP30: SmartBox
®
3
IP54: SmartBox
®
1, 2
Definición
10 Bit
opcional para adaptador
Salida analógica: por ejemplo 0 a 5 V DC; 4 a 20 mA
Material de la carcasa
Policarbonato (PC)
Temperatura ambiente
-10 °C a +50 °C
Sonda de nivel la norma
Tensión de servicio
20 V DC
Materiales
V4A; POM; FPM; PUR
Exactitud
± 1 %
Modelo estándar
250 mbar
Posición de montaje
Suspendido vertical o tendido horizontal
Temperatura ambiente
medio de servicio
-10 °C a +50 °C
Longitud cable conexión
sonda
6 m
Longitud sonda la norma
(sin cable) :97 mm
Ø Sonda: 22 mm
Modo de protección
IP68 según EN 60529
CERTIFICADOS
Nuestro sistema de gestión posee una certificación en conformidad con
ISO 9001, ISO 14001 y ISO 50001, véase:
gok-online.de/de/zertifikate/qualitaets-und-umweltmanagementsystem.
