18 / 20 Artikel-Nr. 28 100 51 g
TECHNISCHE DATEN
Anzeigegerät
Wirkungsweise
Typ 1.B (nach EN 60730-1)
Verschmutzungsgrad
2 (nach EN 60730-1)
Bemessungs-Stoßspannung
4000 V
Versorgungsspannung
230 V AC 50 Hz
Leistungsaufnahme
max. 2 VA
Messeingang
4 bis 20 mA; Uo = 20 V
Relaisausgang
SmartBox
®
2 und 3
Schaltspannung
max. 250 V AC
Schaltstrom
max. 3,5 A
Abmessung H/B/T in mm
194 x 130 x 65 mm
Schutzart nach EN 60529
IP30: SmartBox
®
3
IP54: SmartBox
®
1, 2
Auflösung
10 Bit
Optional per Steckadapter
Analogausgang: z.B. 0 bis 5 V DC; 4 bis 20 mA
Gehäusewerkstoff
Polycarbonat (PC)
Umgebungstemperatur
-10 °C bis +50 °C
Pegelsonde Standard
Spannung
20 V DC
Werkstoffe
V4A; POM; FPM; PUR
Genauigkeit
± 1 %
Messbereich (Standard)
250 mbar
Einbaulage
hängend senkrecht oder liegend waagerecht
Temperaturbereich
Betriebsmedium
-10 °C bis +50 °C
Länge Sondenkabel
6 m
Sondenlänge Pegelsonde
Standard
ohne Kabel: 97 mm
Sondendurchmesser: 22 mm
Schutzart
IP68 nach EN 60529
